TurboLink: Ultra-Low Latency EEG Data Streaming
The TurboLink is a high-performance streaming solution designed for advanced research applications requiring real-time, online access to EEG data. By delivering sub-millisecond data transfers, it is the ideal tool for brain-computer interfaces (BCIs), closed-loop protocols, and EEG-triggered Transcranial Magnetic Stimulation (TMS) where high accuracy and minimum latency are critical.
Key Features
- Ultra-Low Latency: Streams EEG data from the actiCHamp (Plus) amplifier in under 1.5 ms (typically 1 ms) via User Datagram Protocol (UDP).
- Seamless Integration: Works effortlessly with your existing actiCHamp (Plus) and BrainVision Recorder setup, as well as the bossdevice RESEARCH.
- Flexible Data Processing: Connects directly to your preferred data client for real-time processing and brain-state-dependent protocols.
- Dual-Purpose Workflow: Allows the Recorder PC to configure the amplifier via TurboLink while simultaneously monitoring or recording data in the BrainVision File Format for offline validation.
Technical Specifications
Supported Amplifiers: 1 x actiCHamp (Plus)
Channel Capacity: Up to 160 EEG channels + 8 AUX channels
Output Sample Rates: 500 Hz, 1000 Hz, 5000 Hz, and 10000 Hz (all channels supported)
Data Delay: Typical: 1 ms; Upper Limit: 1.5 ms
Data Protocol: User Datagram Protocol (UDP)
Network Adapter: Dual Gigabit (1 GBit/s)
Dimensions (L x W x H): Approx. 12.8 cm x 12.7 cm x 5.7 cm
Weight: Approx. 1.5 kg
Power Requirements
Mains Power Supply Input: 100-240 VAC; 50-60 Hz
Mini PC Power Supply: 19 VDC; 40 W
Operating Conditions:
Temperature: 10 °C to 40 °C (50 °F to 104 °F)
Relative Humidity: 45% to 85% (non-condensing)
Atmospheric Pressure: 700 hPa to 1,050 hPa
Storage and Transport Conditions:
Temperature: 0 °C to 40 °C (32 °F to 104 °F)
Relative Humidity: 45% to 85% (non-condensing)
Atmospheric Pressure: 700 hPa to 1,050 hPa
